Self-supporting suspension wire YTBKW Smooth (air cable)

For self-supporting suspension with end grips e.g. between street light beam up to 25 meters.

Description

single wire (re) or fine-stranded (rf) blanc copper conductor (DIN EN 60228) with synthetic material-insulating cover
traditional braided conductors is wrapped with filling compound
star-shaped, black sheath of highmolecular low density polyethylene
with exellent mechanical qualities and high resistance e.g. against voltage crack formation and oxidation
This cable is produced with enhanced UV and ozone resistance.
approved conductor temperature: 70°C
outer sheath with a smooth surface

Advantages

cable is particularly resistant to degradation by UV and other aggressive compounds in the air
possible enhanced force absorption
enhanced UV- and ozone resistance
easy stripping of outer sheath
coefficient of thermal expansion Et°C = 2,3 x 10-4
tear strength 14 N / mm2
route voltage 8 N / mm2
modulus of elasticity approx. 120 N / mm2
product group complies RL 2011/65/EU
corresponds because of their construction and voltage strength of the protection measure protection class II
smooth outer sheath

Article

Type J Article No.	Type O Article No.	Designation	Metal number	Outer diameter ca. (mm)	Packaging unit (m)
15500	15501	YTBKW Smooth 3 x 1,5 re	43	9,2	50 / 100 / 250 / 500
15506	15507	YTBKW Smooth 3 x 2,5 re	72	11,0	50 / 100 / 250 / 500
15502	15503	YTBKW Smooth 4 x 1,5 re	58	9,4	50 / 100 / 250 / 500
15508	15509	YTBKW Smooth 4 x 2,5 re	96	12,3	50 / 100 / 250 / 500
15504	15505	YTBKW Smooth 5 x 1,5 re	72	11,9	50 / 100 / 250 / 500
15510	15511	YTBKW Smooth 5 x 2,5 re	120	13,2	50 / 100 / 250 / 500
15520	15521	YTBKW Smooth 3 x 1,5 rf	43	8,7	50 / 100 / 250 / 500
15526	15527	YTBKW Smooth 3 x 2,5 rf	72	10,1	50 / 100 / 250 / 500
15522	15523	YTBKW Smooth 4 x 1,5 rf	58	9,7	50 / 100 / 250 / 500
15528	15529	YTBKW Smooth 4 x 2,5 rf	96	14,0	50 / 100 / 250 / 500
15524	15525	YTBKW Smooth 5 x 1,5 rf	72	10,7	50 / 100 / 250 / 500
15530	15531	YTBKW Smooth 5 x 2,5 rf	120	14,8	50 / 100 / 250 / 500
